Honeywell
I-HNVR-1880 : 8 SATA with 10 TB Each, IH+265/H.265/H.264 video formats, HDMI Video output at up to 4K (3840 × 2160) resolution, HDMI and VGA independent outputs, Supports live view, storage, and playback of the connected camera at up to 12MP resolution, IH+265 compression effectively reduces the storage space and costs by up to 75%, Connectable to the third Party cameras, Income 320Mbps; Outgoing 320Mbps, 1 eSATA interface, supports JBOD, RAID0/1/5/6/10
SKU: I-HNVR-1880
About Product
The new Impact series of Network Video Recorders (NVRs) is beneficial to customers who want a higher quality of video surveillance enhanced by HD and an advanced setup. This product can be used for video surveillance in banks, offices, manufacturing industries, warehouses, and parking lots - where image quality and clarity is a key priority. The smart features offered by the new Impact series of NVRs greatly help in the effective analysis of the video feed, while optimizing storage.
Key Specs
- RAID: JBOD, RAID0/1/5/6/10
- ROHS: NA
- SAFETY: NA
- Audio-in: 1-ch, 3.5mm
- Bandwidth: 320Mbps IN & 320 Mbps Out
- COMPRESSION: IH+265/H.265/H.264
- Audio Output: 1x3.5mm, 1xBNC
- Max Resolution: 12 MP
- No.Of Channels: 80
- HDMI/VGA Output: Available
- INTERNAL SATA Ports: 8
- EXTERNAL HDD (eSATA Port): 1
Or
Product Specifications
Video
No.Of Channels
80
Max Resolution
12 MP
Bandwidth
320Mbps IN & 320 Mbps Out
HDMI/VGA Output
Available
Screen Split
1/3/4/6/8/9/10/13/16/20A/20B/25/32/36/40/64
Audio
Audio-in
1-ch, 3.5mm
Audio Output
1x3.5mm, 1xBNC
Recording
COMPRESSION
IH+265/H.265/H.264
RESOLUTION
up to 12 MP
FRAME RATE
25FPS
RECORD BIT RATE
NA
BIT RATE1
NA
RECORDING MODE
NA
RECORDING INTERVAL
NA
PRE-EVENT RECORDING INTERVAL
NA
POST-EVENT RECORDING INTERVAL
NA
VIDEO DETECTION AND ALARMS
TRIGGER EVENTS
Yes
VIDEO DETECTION
Motion, Intrusion, Perimeter
ALARM INPUT
Available
RELAY OUTPUT
Available
PLAYBACK AND BACKUP
SYNC PLAYBACK
2x12MP, 4x8MP, 4x6MP, 5x5MP, 8x4MP, 9x3MP, 16x1080P, 16x720P
SEARCH MODE
Available
PLAYBACK FUNCTION
Available
BACKUP MODE COMPATIBILITY
Yes
NETWORK
ETHERNET
2xRJ45 self-adaptive 10/100/1000 Mbps network interface
POE
NO
SUPPORTED PROTOCOLS2
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, I GMP, QoS, IPV4, IPV6, Multicast, ARP, UDP, SNMP, SSL, Telnet, RTMP, NFS
MAXIMUM NUMBER OF USERS
10
NETWORK THROUGHPUT
640
SMART PHONE COMPATIBILITY
Yes
STORAGE
INTERNAL SATA Ports
8
EXTERNAL HDD (eSATA Port)
1
RAID
JBOD, RAID0/1/5/6/10
AUXILIARY INTERFACE
USB PORTS
2xUSB 2.0, 1xUSB 3.0
RS232
2xRS-485, 1xRS-232
ELECTRICAL
POWER SUPPLY
AC100~240V, 50/60HZ
POWER CONSUMPTION
≤100W (without HDD)
ENVIRONMENTAL
OPERATING TEMPERATURE
-10°C~55°C,
RELATIVE HUMIDITY
10%~90% RH
STORAGE TEMPERATURE
NA
PHYSICAL
DIMENSIONS
94×440×460mm, (3.7×17.32×18.11 inch)
WEIGHT (WITHOUT HDD)
7.2Kg (15.87lb)
REGULATORY
EMISSIONS
NA
IMMUNITY
NA
SAFETY
NA
ROHS
NA
